CMV 563 / M 7 S
Vacuum tube condenser microphone
> Original M 7 S gold plated PVC capsule
> Modular capsule system
> Cardioid polar pattern
> Backwards compatible to vintage M 7, M 8, M 9, M 55 K
The new CMV 563 M 7 S is the original reissue of the vintage Gefell CMV 563.
It has the typical warm, full-bodied sound of valve microphones that are preferred by vocalists and soloists.
The vacuum tube preamplifier is equipped with the EF 86 pentode working as a triode selected for its sonic characteristics.
The new N 61 power supply provides the operating voltage for the vacuum tube. It can be powered from AC mains with a primary voltage of 115 or 230 volts / 50 or 60 Hz. The N 61 is equipped with an on/off switch, a 7-pin Tuchel connector that powers the microphone and a 3-pin XLR connector.
The CMV 563 M 7 S is packed in a mahogany colour wooden box and comes with power supply N 61, connection cable C 563.1, elastic suspension EA 92 and G/B adaptor for the use of vintage bayonet M 7, M 8, M 9 capsules.
